Coiled tubing hanger is used in siphon string operation to hang coiled tubing for the size of 1.25”to 2.375” in the well head. The size and style of flange can be customized according to customer’s requirements. The body of the coiled tubing surface hanger is fabricated with forged material and the slip adopts split design for convenient installation. The rubber drum relies on coiled tubing gravity and set screw to ensure sealing performance.
CT Size | Up and Down Flange Size | Side Flange Size | Pressure Rating (MPa) |
| 1.25-2" | 2 9/16"-4 1/16" | 2 9/16"-4 1/16" | 35-105 |
| 1.25-2" | 2 9/16"-4 1/16" | # | 35-105 |
| 1.25-2" | 2 9/16"-4 1/16" | 螺柱法兰 | 35-105 |
Coiled tubing hanger is used in siphon string operation to hang coiled tubing for the size of 1.25”to 2.375” in the well head. The size and style of flange can be customized according to customer’s requirements. The body of the coiled tubing surface hanger is fabricated with forged material and the slip adopts split design for convenient installation. The rubber drum relies on coiled tubing gravity and set screw to ensure sealing performance.
CT Size | Up and Down Flange Size | Side Flange Size | Pressure Rating (MPa) |
| 1.25-2" | 2 9/16"-4 1/16" | 2 9/16"-4 1/16" | 35-105 |
| 1.25-2" | 2 9/16"-4 1/16" | # | 35-105 |
| 1.25-2" | 2 9/16"-4 1/16" | 螺柱法兰 | 35-105 |
