Dimple-On Connector
To be the leading manufacturer of downhole tools
Home - Products - Primay Tools
  • introduction
  • Features
  • Specifications
Product introduction

Dimple-on connector uses 12 pits to connect with coiled tubing, and uses double sealing rings to achieve high pressure sealing. Dimple-on connector must be used together with dimpling tool.

Product Features
Suitable for 1-1/2 "to 2-7/8" tools
High torque resistance
The connector is reusable and comes with a standard redress kit with o-ring.
Specifications

OD(mm)

ID(mm)

Connection

Length(mm)

Pressure Rating (MPa)

Tensile Strength(T)

38201"AMMT2033520
43171"AMMT2033529
44.5191"AMMT2033530
50.825.41-1/2"AMMT2033536.2
60.325.41-1/2"AMMT3053543
73352-3/8"PAC3053543
Product introduction

Dimple-on connector uses 12 pits to connect with coiled tubing, and uses double sealing rings to achieve high pressure sealing. Dimple-on connector must be used together with dimpling tool.

Product Features
Suitable for 1-1/2 "to 2-7/8" tools
High torque resistance
The connector is reusable and comes with a standard redress kit with o-ring.
Specifications

OD(mm)

ID(mm)

Connection

Length(mm)

Pressure Rating (MPa)

Tensile Strength(T)

38201"AMMT2033520
43171"AMMT2033529
44.5191"AMMT2033530
50.825.41-1/2"AMMT2033536.2
60.325.41-1/2"AMMT3053543
73352-3/8"PAC3053543
