Double dimple-on Connector is used to connect two sections of coiled tubing. Both ends of the connector are respectively provided with 12 pits. Hydraulic dimpling tool can be used to crimp the coiled tubing into the dimple profile to connect the coiled tubing.
OD (mm) | ID (mm) | Length(mm) | Pressure Rating (MPa) | Tensile Strength (T) |
| 31.75 | 10.16 | 183 | 35 | 13 |
| 38 | 14 | 183 | 35 | 25 |
| 44.5 | 19 | 190.5 | 35 | 25 |
| 50.8 | 25.4 | 190.5 | 35 | 36 |
| 60.3 | 31.75 | 216 | 35 | 43 |
| 73 | 35 | 228.6 | 35 | 50 |
Double dimple-on Connector is used to connect two sections of coiled tubing. Both ends of the connector are respectively provided with 12 pits. Hydraulic dimpling tool can be used to crimp the coiled tubing into the dimple profile to connect the coiled tubing.
OD (mm) | ID (mm) | Length(mm) | Pressure Rating (MPa) | Tensile Strength (T) |
| 31.75 | 10.16 | 183 | 35 | 13 |
| 38 | 14 | 183 | 35 | 25 |
| 44.5 | 19 | 190.5 | 35 | 25 |
| 50.8 | 25.4 | 190.5 | 35 | 36 |
| 60.3 | 31.75 | 216 | 35 | 43 |
| 73 | 35 | 228.6 | 35 | 50 |
