External grapple connector an external type connector that engages the outer diameter of the coil tubing. The slip ensures that axial load is transferred into the tubing, increasing the strength of the connector grip on the tubing. The connector design provides an uninterrupted bore for drop ball operations while locking screws prevent the service connection backing off and the anti-rotation screws prevent the coil tubing rotating inside the connector once assembled.
l Suitable for all sizes of coiled tubing
l Locking screw ensures the stabilization of the connector
Slip achieves the connection strength between connector and coiled tubing.
CT Size | OD (mm) | ID (mm) | Connection | Length (mm) | Pressure Rating (MPa) | Tensile Strength (T) |
| 1-1/2" | 54 | 25.4 | 1-1/2"AMMT | 304.8 | 35 | 22 |
| 1-3/4" | 60 | 25.4 | 1-1/2"AMMT | 304.8 | 35 | 34 |
| 2" | 73 | 35 | 2-3/8"PAC | 381 | 35 | 45 |
| 2-3/8" | 79.4 | 35 | 2-3/8"PAC | 381 | 35 | 54 |
| 2-7/8" | 95 | 44 | NC26 | 457.2 | 35 | 90 |
External grapple connector an external type connector that engages the outer diameter of the coil tubing. The slip ensures that axial load is transferred into the tubing, increasing the strength of the connector grip on the tubing. The connector design provides an uninterrupted bore for drop ball operations while locking screws prevent the service connection backing off and the anti-rotation screws prevent the coil tubing rotating inside the connector once assembled.
l Suitable for all sizes of coiled tubing
l Locking screw ensures the stabilization of the connector
Slip achieves the connection strength between connector and coiled tubing.
CT Size | OD (mm) | ID (mm) | Connection | Length (mm) | Pressure Rating (MPa) | Tensile Strength (T) |
| 1-1/2" | 54 | 25.4 | 1-1/2"AMMT | 304.8 | 35 | 22 |
| 1-3/4" | 60 | 25.4 | 1-1/2"AMMT | 304.8 | 35 | 34 |
| 2" | 73 | 35 | 2-3/8"PAC | 381 | 35 | 45 |
| 2-3/8" | 79.4 | 35 | 2-3/8"PAC | 381 | 35 | 54 |
| 2-7/8" | 95 | 44 | NC26 | 457.2 | 35 | 90 |
