Low speed spinning wash tool is a dedicated high pressure rotating wash tool suitable for tough downhole CT clean-out operations. The G-Spinning tool uses a unique turbine and sealing ring in order to rotate the nozzles in a controlled speed. The high pressure jet nozzles deliver a powerful cleaning force to enable the penetration of the typical hydrates, paraffin wax, barium, calcium or mineral scales commonly found in well bores, without damaging the pipe structure. An internal centrifugal speed control maintains rotation speeds of 30 to 200 rpm.
l Low rotation speed to maximize jet power.
l Dynamic speed adjustment
The replacement nozzle can be used in sandwashing cutting operations
OD (mm) | ID (mm) | Connection | Flow Rate (Lpm) | Rotate Speed (rpm) | Pressure (MPa) |
| 43 | 9.9 | 1"AMMT | 70-150 | 30-150 | 35 |
| 44.5 | 9.9 | 1"AMMT | 70-150 | 30-150 | 35 |
| 54 | 14 | 1-1/2"AMMT | 80-170 | 40-200 | 35 |
| 73 | 20.3 | 2-3/8"PAC | 200-400 | 30-200 | 35 |
Low speed spinning wash tool is a dedicated high pressure rotating wash tool suitable for tough downhole CT clean-out operations. The G-Spinning tool uses a unique turbine and sealing ring in order to rotate the nozzles in a controlled speed. The high pressure jet nozzles deliver a powerful cleaning force to enable the penetration of the typical hydrates, paraffin wax, barium, calcium or mineral scales commonly found in well bores, without damaging the pipe structure. An internal centrifugal speed control maintains rotation speeds of 30 to 200 rpm.
l Low rotation speed to maximize jet power.
l Dynamic speed adjustment
The replacement nozzle can be used in sandwashing cutting operations
OD (mm) | ID (mm) | Connection | Flow Rate (Lpm) | Rotate Speed (rpm) | Pressure (MPa) |
| 43 | 9.9 | 1"AMMT | 70-150 | 30-150 | 35 |
| 44.5 | 9.9 | 1"AMMT | 70-150 | 30-150 | 35 |
| 54 | 14 | 1-1/2"AMMT | 80-170 | 40-200 | 35 |
| 73 | 20.3 | 2-3/8"PAC | 200-400 | 30-200 | 35 |
