Product introduction

Mechanical bow spring centralizer is used to center the tool inside the casing by four custom bow springs. The expansion and retraction of the bow spring are controlled by the compression spring. The bow spring is made of special material with long life to ensure the stability of its elastic properties.

Product Features
定制化的弓形弹簧
特殊表面处理
Specifications

OD

(mm)

Max

OD

ID

 (mm)

Connection

Length(mm)

Pressure

Tensile

43150131"AMMT7193513
44150131"AMMT7193513
54127151-1/2"AMMT6733520
57127151-1/2"AMMT6433533.5
64178201-1/2"AMMT7703543
73178252-3/8"PAC8203543
79180302-3/8"PAC7873537.5
